Overview
Overview
| Product | Turbidity sensor |
| Measure range | 0.01-100NTU |
| Measurement Accuracy | The deviation of reading in 0.001~40NTU is ±2% or ±0.015NTU, choose the bigger one; and it is ±5% in the range of 40-100NTU |
| Flow Rate | 300ml/min≤X≤700ml/min |
| Pipe Fitting | Injection Port: 1/4NPT; Discharge Outlet: 1/2NPT |
| Environment temp | 0~45℃ |
| Calibration | Standard Solution Calibration, Water Sample Calibration, Zero Point Calibration |
| Cable length | Three-meter standard cable, it is not recommended to extend |
| Main materials | Main Body: ABS + SUS316 L, |
| Sealing Element: Acrylonitrile Butadiene Rubber | |
| Cable: PVC | |
| Ingress protection | IP66 |
| Weight | 2.1 KG |
Product Features
Product Features
Application
Application
Order Information
Order Information
| Product | Turbidity sensor |
| Measure range | 0.01-100NTU |
| Measurement Accuracy | The deviation of reading in 0.001~40NTU is ±2% or ±0.015NTU, choose the bigger one; and it is ±5% in the range of 40-100NTU |
| Flow Rate | 300ml/min≤X≤700ml/min |
| Pipe Fitting | Injection Port: 1/4NPT; Discharge Outlet: 1/2NPT |
| Environment temp | 0~45℃ |
| Calibration | Standard Solution Calibration, Water Sample Calibration, Zero Point Calibration |
| Cable length | Three-meter standard cable, it is not recommended to extend |
| Main materials | Main Body: ABS + SUS316 L, |
| Sealing Element: Acrylonitrile Butadiene Rubber | |
| Cable: PVC | |
| Ingress protection | IP66 |
| Weight | 2.1 KG |
Installation
Product dimension
