Overview
Overview
| Product | TDS meter, EC controller |
| Model | SUP-TDS210-B |
| Measure range | 0.01 electrode: 0.02～20.00us/cm |
| 0.1 electrode: 0.2～200.0us/cm | |
| 1.0 electrode: 2～2000us/cm | |
| 10.0 electrode: 0.02～20ms/cm | |
| Accuracy | ±1%FS |
| Stability | ±1%FS/24H |
| Measuring medium | Liquid |
| Input Resistance | ≥10~12Ω |
| Temp compensation | Manual/ Auto temperature
compensation |
| Temperature Range | -10-130℃， NTC10K or PT1000 |
| Communication | RS485, Modbus-RTU |
| Signal output | 4-20mA, maximum loop 750Ω, 0.1%FS |
| Power supply | AC220V±10%, 50Hz |
| Relay output | 250V, 3A |
Product Features
Product Features
SUP-TDS210-B online conductivity/resistivity analyzer, an intelligent online chemical analyzer, is widely applied for continuous monitoring and measurement of EC value or TDS value or EC value and temperature in the solution in the industry of thermal power, chemical fertilizer, environmental protection, metallurgy, pharmacy, biochemistry, food and water, etc.
Order Information
Order Information
| Product | TDS meter, EC controller |
| Model | SUP-TDS210-B |
| Measure range | 0.01 electrode: 0.02～20.00us/cm |
| 0.1 electrode: 0.2～200.0us/cm | |
| 1.0 electrode: 2～2000us/cm | |
| 10.0 electrode: 0.02～20ms/cm | |
| Accuracy | ±1%FS |
| Stability | ±1%FS/24H |
| Measuring medium | Liquid |
| Input Resistance | ≥10~12Ω |
| Temp compensation | Manual/ Auto temperature
compensation |
| Temperature Range | -10-130℃， NTC10K or PT1000 |
| Communication | RS485, Modbus-RTU |
| Signal output | 4-20mA, maximum loop 750Ω, 0.1%FS |
| Power supply | AC220V±10%, 50Hz |
| Relay output | 250V, 3A |
Installation
