Technical Specifications
- Measurement Diameter: DN6 … DN50
- Power Supply Voltage: 16 … 30Vdc
- Output Types:
- Switch Output (PNP/NPN)
- Analog Output (4-20mA)
- Pulse
- Output Current: <500mA
- Response Time: <10ms
- Switch Accuracy: ≤±0.5% of the range
- Current Type Analog Output: ≤±0.5% of the range
- Wiring Protection: Reverse polarity, overload, segment protection
- Display: OLED LCD screen
- Pressure Resistance: 400bar
- Temperature:
- Measurement Range: 0 … 100℃
- Ambient Temperature: -20 … 80℃
- Storage Temperature: -30 … 80℃
- Accuracy: ≤±1% of the range
- Materials:
- Housing: Aluminum oxide
- Shell: Stainless steel 304
- Turbine: Duplex steel
- Protection Level: IP67
- Output Connection: M12x1 connector
