Translated Data:
- Setting Range: 1—150cm/s (Water), 3—300cm/s (Oil), 20—2000cm/s (Air)
- Signal Output: PNP, NPN, Relay, Normally Open (SPDT)
- Power Supply: 24V ±20% DC, 220V AC
- Input Source: Max 400mA (PNP or NPN Type), Max 1A 48V AC/DC (Relay Type)
- No Load Current: Max 80mA
- Flow Indicator: LED Array (6 LEDs)
- Setting Method: Electrical Setup
- Pressure Resistance: 100 bar
- Medium Temperature Change Rate: ≤4℃/s
- Response Time: 1—13s, Typical Value 2s
- Startup Time: About 8s
- Electrical Protection: Reverse Polarity, Short Circuit, Overload Protection
- Protection Class: IP67
- Medium Temperature: -20—90℃
- Ambient Temperature: -20—80℃
- Storage Temperature: -20—100℃
- Connection Type: M12 Connector
- Housing Material: Probe: Stainless Steel (304), Housing: Stainless Steel (304)
- Measurement Accuracy: ±1%
