Technical Specifications
- Measuring Range: 1—150 cm/s (water), 3—300 cm/s (oil), 20—2000 cm/s (air)
- Signal Output: PNP, NPN, Relay Output, Normally Open (SPDT)
- Power Supply: 24V ±20% DC
- Connection Current: Maximum 400mA (PNP or NPN type), Maximum 3A 24V AC/DC (Relay type)
- No-load Current: Maximum 80mA
- Flow Indication: LED Array (6 units)
- Setpoint: Electrical Setpoint
- Pressure Range: 100 bar (customizable up to 40MPa)
- Ambient Temperature: < 4°C
- Response Time: 1—13 seconds, typically 2 seconds
- Start Delay: About 8 seconds
- Electrical Protection: Reverse Polarity, Short Circuit, Overload Protection
- Explosion-proof Grade: Exd II CT6
- Protection Rating: IP67
- Medium Temperature: -20°C—100°C (customizable from -60°C to 150°C)
- Ambient Temperature: -20°C—80°C
- Storage Temperature: -20°C—100°C
- Process Connection: Threaded Connection M20*1.5
- Material: Housing: Stainless Steel (customizable 316L / Titanium / PVDF / Teflon), Exterior: Nickel Plating
- Accuracy: ±2%
