Technical Specifications:
- Set Range: 1…150 cm/s (Water), 3…300 cm/s (Oil), 20…2000 cm/s (Air)
- Signal Output: PNP, NPN, Relay (SPDT with Normally Open & Normally Closed)
- Power Supply: 24V ± 20% DC
- Contact Capacity: Max 400 mA (PNP or NPN type), Max 1A 48VAC/DC (Relay type), 4A 24VDC (Relay type)
- No-load Current: Max 80 mA
- Flow Indicator: LED (6 units)
- Set Method: Electric position setting
- Pressure Range: 100 bar
- Medium Temperature Change Rate: ≤4°C/s
- Response Time: 1…13 s, typical value 2 s
- Initialization Time: Approximately 8 s
- Electrical Protection: Reverse polarity, short circuit, overload protection
- Protection Level: IP67
- Medium Temperature: -20…90°C (High-temperature version available: -40…150°C)
- Ambient Temperature: -20…80°C
- Storage Temperature: -20…100°C
- Connection Method: M12 connector
- Material: Probe: Stainless Steel (304/316 optional), Housing: POM (Engineering Plastic)
- Repeatability: ±2%
