Liquid, Gas Filled Available
Optional Type:
- SRG-QS: Surface mount sensor bulb c/w every angle connection
- SRG-W: Surface mount sensor bulb c/w capillary & wall mounting flange
- SRG-P: Surface mount sensor bulb c/w capillary & panel mounting flange
Dial Size: 100, ø150mm available
Case & Cover Material: SS304 or SS316 available
Stem Material: SS316
Lens: Glass, Safety glass available
Sensor Bulb Capillary Tube, Flex Tube Material: SS304
Capillary Tube Length Limited: Liquid filled type: 10M
Gas filled type: max. 50M; option available
Housing Enclosure: IP66, liquid filled available
Range Limit: -200°C to +650°C available
Stem Dimensions: Ø10, 12mm; option on request
Stem Length Limit: Standard 100mm(H); option on request
Sensor Bulb Length: Standard 120mm(L); option on request
Accuracy: ±1% F.S.
Over Range Protection: 130% F.S.
Switch Form:
- Limit Switch: available 7 functions for usage
- Micro Switch: One setting point SPDT x 1 or Two setting points SPDT x 2
Switch Data: Please see the Contact Type Assemblies Table
