Case Material:
Aluminum alloy case with paint, SS316 available
Body Wetted Parts Material:
SS316; SS316+PTFE lining (PVDF float);
Others on request; Indication via magnetic coupling (no sealed)
Flow Rate for:
SS316 Float:
Water- 1 L/H up to 200,000 L/H (special ranges on request)
Air- 0.03 Nm³/H up to 5,400 Nm³/H (special ranges on request)
PVDF Float:
Water- 4 L/H up to 10,000 L/H (special ranges on request)
Air- 0.13 Nm³/H up to 180 Nm³/H (special ranges on request)
Options:
Micro Switch 5A/125VAC, 5A/250VAC, 2A/30VDC;
Adjustable Reed Alarm Switch, Form A bistable type, N.O. type;
Adjustable Inductive Alarm Switch;
4~20mA (2-wires) analog output
