Service:for using in Non-Corrosive gas
Output Signal: 0~5 VDC linear min. load 1000Ω or 4~20mA linear, loop resistance 500Ω
Input Power: 24VDC standard; optional power supply 15VDC 115VAC, 220VAC@500mA
Process Connection: ¼”NPT female
Flow Range:
0~10 SCCM to 50 SLM (24VDC)
0~10 SCCM to 20 SLM (15VDC)
Operating Differential Pressure: FS ≤ 5SLM (0.5~3 kg/cm²)
